HF1304 Series Ceramic Igniter

Name: HF1304 Series Ceramic Igniter
Brand: HEAT FOUNDER Silicon Nitride Igniter, Silicon Nitride Heating Element
SKU: HF1304 Series
Availability: InStock
Rating: 5 (1 reviews)

Item No.: HF1304 Series

Designed for industrial heating systems, the HF1304 Series ceramic igniter ensures reliable ignition with fast startup. Ideal for integration with hot water heater igniter and ceramic heater elements.

Ask for a Solution PDF Format

Description DRAWING

Targeted Usage in Heating Systems and Industrial Clients
The HF1313 Series ceramic igniter is engineered primarily for heating system manufacturers and industrial integrators requiring a dependable ignition component. It functions as a critical element within assemblies involving water heater element replacement or advanced ceramic heater systems. This product supports environments necessitating consistent thermal ignition performance, such as residential and commercial hot water heater igniter modules. By serving industries focused on energy-efficient and long-term operation, this igniter provides a foundational ignition source contributing to overall system safety and reliability. Its compatibility with multiple flange materials further enhances adaptability to varied engineering design requirements in heating applications.

Advanced Construction and Precise Electrical Specifications
Constructed from 96% alumina ceramic, the HF1313 Series igniter delivers stable operation across a broad temperature range, from 30°C to 1050°C, suitable for demanding thermal conditions. Voltage options of 120V and 230V with power ratings of 260W and 300W enable precise matching to system power profiles. Custom flange options in ceramic, stainless steel, or copper provide structural integration flexibility. The igniter achieves gas or fuel ignition within 40 to 60 seconds, optimizing startup efficiency in hot water heater igniter assemblies or ceramic heater elements. Rigorous quality control, including ISO9001 and SGS certifications, assures compliance with industrial standards, facilitating incorporation in certified system designs requiring certified hot water heater element replacements.

Versatile Industry Applications and Operational Value
The HF1313 Series igniter finds extensive application in the ignition of biomass boilers, pellet stoves, and gas burners, where reliable initiation of combustion is vital. It also serves as a safe ignition source in BBQ grills and stove fireplaces, extending to niche areas such as medical-scientific instrumentation and agricultural heaters. Its role significantly impacts fuel cell ignition and electric vehicle heating systems, demonstrating broad functional adaptability. Integration within complex gas appliance ignition systems enhances operational safety and reduces downtime, underpinning its value in environments demanding long service intervals and efficient ignition under variable load conditions. This solution supports end-users seeking precise control in hot water heater element replacement or ceramic heater elements deployment.

Product Advantages

Design and Structural Integration Benefits
The HF1313 Series incorporates a high-purity 96% alumina ceramic base, providing robust thermal resistance fundamental to the product’s exceptional durability under prolonged exposure to temperatures up to 1050°C. Modular flange configurations—ceramic, stainless steel, copper, or customized—enable seamless mechanical integration with various heating assemblies, especially those utilizing hot water heater igniter setups or water heater element replacements. The compact 11.5 mm tube diameter and specific length dimensions allow incorporation into constrained spaces without compromising performance. Engineering precision supports conformity to system design parameters, ensuring the igniter operates within required physical tolerances and facilitates retrofit in legacy or new heating systems.

Operational Efficiency and User-Centric Performance
Performance-wise, the HF1313 Series ensures ignition within a controlled 40 to 60 seconds, minimizing startup delays and reducing fuel wastage during system warm-up phases. Its dual voltage and power rating options allow end-users to optimize energy consumption relative to application demands. The product’s compliance with multiple global certifications (BSCI, SGS, ISO9001) affirms its reliability and safety in industrial contexts. Its compatibility with ceramic heater elements and hot water heater element replacements supports maintenance operations by providing a durable ignition source with reduced frequency of replacement. This translates to lower operating costs and system downtime, enhancing overall asset value for industrial heating equipment operators.

Name	Ceramic Igniter
Model	HF1304 Series
Material	96% alumina
H.S. Code	8516800000
Voltage	220V
Power	150W
Flange	Ceramic/Stainless Steel/copper/customized
Temp Range	30~1050 °C/86~1922℉
Ignition Time	40-60 seconds
Samples fee	Please contact for confirmation.
Packing	carton
Lead time	5 working days for samples; 12 working days for mass production
QC	Strict quality control under SGS, ISO9001 and Intertek.
Certification	BSCI, ISO9000/1400,BV TUV SGS FSC etc.
Applications
Biomass boiler/burner	Pellet burners
Gas burner/stove	Pellet boiler
Ignition of gas or oil	Pellet burner
Pellet Stove	Pellet BBQ grill
Stove fireplace	Medical-Scientific
Wood pellet stove	Heaters-Agricultural
Particle Burning	Spark Igniters
Fuel cells	EV heating
Gas appliances	Glow plug
Petroleum equipment	Cabin heater
Soldering iron	Gas sensor
gas furnaces,	DPF/Catalyst
gas boiler

Model Number	Voltage(V)	Rating power(W)	OD.tube(mm)	Total length L1(MM)	Max.OD.flange(MM)
HF1304A01-B	220	150	22	170	20

Use Scenarios

Ignition Solution in Biomass Boilers and Pellet Stoves
Within biomass boiler and pellet stove environments, the HF1313 Series ceramic igniter serves as the primary ignition source for particulate and gaseous fuels. These systems operate under stringent efficiency and emission control regulations necessitating predictable ignition timing and durability. The igniter’s ceramic heater composition resists thermal shock and corrosion, sustaining performance during repeated thermal cycles. Effective ignition within 40-60 seconds facilitates rapid transition to steady-state combustion, optimizing heat output and fuel consumption. Integrated into control systems, the igniter interfaces with automated burners, improving operational consistency and meeting sustainability compliance through minimized incomplete combustion incidents. It supports system operators by delivering reliable ignition aligned with energy-saving protocols.

Application in Gas Burners and Residential BBQ Grills
In gas burner and residential BBQ grill contexts, the HF1313 Series igniter fulfills the critical role of reliable flame initiation under variable ambient conditions. Its rapid ignition capability enhances user safety by reducing unburned fuel accumulation during startup sequences. The igniter’s design enables compatibility with hot water heater igniter circuits or standalone ceramic heater elements, providing flexible retrofit options. Temperature resilience ensures performance stability despite fluctuating external temperatures. Compliance with international certifications supports installation in regulated residential and light commercial applications. The igniter integrates within gas safety systems, providing feedback for ignition confirmation and fault detection, which collectively elevate operational safety standards and user confidence.

FAQ

What materials are used in the HF1304 Series Ceramic Igniter?
Our HF1304 Series Ceramic Igniter is made primarily from 96% alumina ceramic, ensuring high mechanical and thermal stability. The flange can be customized with ceramic, stainless steel, copper, or other materials, supporting reliable performance in diverse heating systems.

Can you customize the HF1304 Series for specific applications?
Yes, we offer customization for flange types and dimensions to fit your precise requirements. This flexibility ensures compatibility with various heating appliances, including those using hot water heater elements or industrial ignition systems.

How should I install the HF1304 Series Ceramic Igniter in my heating equipment?
We recommend following standard industrial installation procedures for ceramic igniters. Ensure proper flange fitting to avoid stress on the ceramic element. Our technical support is available to guide you through compatibility with systems like water heater element replacement setups.

What logistics and lead times can I expect for ordering the HF1313 igniter?
Sample orders typically require 5 working days for production. We maintain strict quality control under SGS and ISO certifications to ensure prompt delivery of fully compliant ceramic heater elements tailored to your project timelines. Contact us for detailed scheduling.
